Tools

Watts to dBm
and
Watts to dBW converter

Watts to dBm
W = 30 dBm
miliWatts to dBm
mW = 0 dBm
Watts to dBW
W = 0 dBW
miliWatts to dBW
mW = -30 dBW

dBm to Watts
and
dBW to Watts converter

dBm to Watts
dBm = 0.001 W
dBm to miliWatts
dBm = 1 mW
dBW to Watts
dBW = 1 W
dBW to miliWatts
dbW = 1000 mW

Frequency to Wavelength
and
Wavelength Converter


Frequency to Wavelength
MHz = 0.149896229 m

Wavelength to Frequency
m = 299.792458 MHz

Free Space Loss
Calculator

Distance from the Tx to the Rx (in km)

km

Frequency of the link (in MHz)

MHz

Free Space path loss in dB

= 155.37034393544812 dB

Orbital Speed
and Period
Calculator

Altitude of the satellite (in km)

km

Radius of planet (in km) (default value is set for Earth, i.e. 6378 km)

km

Standard gravitational parameter (default value is set for Earth, i.e. 398600.418 km3/s2)

km3/s2

Speed of the satellite (in km/s)

= 7.504358891574406 km/s

Orbital period of the satellite (in minutes)

= 98.77011979919413 min

Binary number converter

Binary Number to convert



In Decimal

= 255

In Hex

= FF

Decimal number converter

Decimal Number to convert



In Binary

= 11111111

In Hex

= FF

Hex number converter

Hex Number to convert



In Binary

= 11111111

In Decimal

= 255

Tx/Rx Frequency
Ratio
(CCSDS Recommendation:
221/240)


Tx to Rx Frequency
MHz = 2400 MHz

Rx to Tx Frequency
MHz = 2210 MHz

TM Pseudo-Randomization
(CCSDS Recommendation)
Input in Binary

Non-randomized number in binary



Pseudo-random sequence

= 1111111101001000

Randomized number

= 0000000010110111

Randomized number in Hex

= 00B7

Note: Inserting a randomized number in the input field will give you a non-randomized number in the output fields

TM Pseudo-Randomization
(CCSDS Recommendation)
Input in Hex

Non-randomized number in Hex



Non-randomized number in Binary

= 1111111111111111

Pseudo-random sequence

= 1111111101001000

Randomized number

= 0000000010110111

Randomized number in Hex

= 00B7

Note: Inserting a randomized number in the input field will give you a non-randomized number in the output fields

TC Pseudo-Randomization
(CCSDS Recommendation)
Input in Binary

Non-randomized number in binary



Pseudo-random sequence

= 1111111100111001

Randomized number

= 0000000011000110

Randomized number in Hex

= 00C6

Note: Inserting a randomized number in the input field will give you a non-randomized number in the output fields

TC Pseudo-Randomization
(CCSDS Recommendation)
Input in Hex

Non-randomized number in Hex



Non-randomized number in Binary

= 1111111111111111

Pseudo-random sequence

= 1111111100111001

Randomized number

= 0000000011000110

Randomized number in Hex

= 00C6

Note: Inserting a randomized number in the input field will give you a non-randomized number in the output fields
